Hydraulic Stone Stamping Machine for Granite Marble Stone

Our hydraulic stone stamping machine is an excellent choice to change waste granite marble stone into valued paving tiles. Every stone processng factory produces a lot of waste slabs of marbles and granites during the production, which is a big waste and occupy a large number of sites.

How does the hydraulic stone stamping machine work ?

marble granite stone

marble stone paving tiles



It is used to stamp different shape of stones by equipping with different moulds. It is a great machine to change the waste slabs into valued paving tiles, Two models SS-300 and SS-300A available. It can stamp / Press the stone tiles thickness from 1cm up to 5cm .  Moulds could be customized as per customer’s different brick design.

Specially designed tooling to get mould replacing easily, it only takes 3min to replace the mould.

MODELSS300SS300A
Overall dimensions1600X900X1580mm1700X900X1580mm
Weight1000KG1000KG
Power4KW5.5KW
Voltage380V380V
Frequency50HZ50HZ
Pressure0----50T0----80T
Hydraulic fluid type4646
Table size570X350680X350
Output per hour10M210M2
